Engine

Engine Type 4-Stroke DOHC Twin CylinderCylinders-Displacement (cc) 999ccCooling LiquidEngine Power 110 HPFuel System Electronic Fuel InjectionElectronic Power Steering Standard with Quick Turn Rack

Drivetrain

Drive System High Performance True On-Demand AWD/2WDTransmission Automatic PVT P/R/N/L/H

Suspension

Front Suspension Dual A-Arm with Stabilizer BarRear Suspension Trailing Arm with Stabilizer BarFront Shocks 2" Walker Evans Needle Shocks with 16-Position Adjustable ClickersRear Shocks 2.5" Walker Evans Needle Shocks with 16-Position Adjustable ClickersFront Travel (in./cm.) 20 in (50.8 cm)Rear Travel (in./cm.) 20 in (50.8 cm)

Brakes

Front braking system 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear CalipersRear braking system 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear CalipersParking Brake Park In-Transmission

Wheels & Tires

Wheels Cast AluminumFront Tire 29 x 9-14; Radial TireRear Tire 29 x 11-14; Radial TireFront Wheel Travel 16 in (40.6 cm)Rear Wheel Travel 18 in (45.7 cm)DimensionsBed Box Dimensions (LxWxH) 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm)Ground Clearance 14 in (35.6 cm)Overall Vehicle Size (LxWxH) 146 x 64 x 73.75 in (370.8 x 162.6 x 187.3 cm)Wheelbase 117 in (297.2 cm)

Capacities

Box Capacity 300 lb (136.1 kg)Fuel Capacity 9.5 gal (35.9 L)Payload Capacity 900 lb (408 kg)

WeightsEstimated

Dry Weight (lbs./kgs.) 1,671 lbs (758 kg)

Lights andSafety

Lighting Signature White LED, Low/High & Red LED Tail / Brake Lights

Features

Cargo System Lock & Ride®Seat Type Bolstered Bucket Seats with Driver Seat Slider and Height Adjustable Seat BeltsFeatures Doors: Front & Rear Bowed 1/4 Doors | Other Standard: Adjustable Tilt SteeringInstrumentation Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet
