Engine

Engine Type V-Twin cylinder, 4 strokes, 8 valvesEngine Management Fuel injected engineDisplacement 963ccCooling System LiquidBore 91 (3.6 in)Stroke 74 mm (2.9 in)Compression Ratio 10.6: 1Starter

ElectricBattery

Battery 30 AmpDrivetrainDrivetrain

Powertrain: 2WD / 4WD, electric locking differentialGearbox L / H / N / R / P (parking lock shift system)Clutch CV-Tech IBC

clutch system:

CV-Tech IBC clutch system variable transmission.Steering Electric Power Steering (EPS)SuspensionFront Suspension Double A-arm, independent suspension, gas shock absorber with adjustable rebound/compressionFront Travel (in./cm.) 180 mm (7 in)Rear Suspension Independent trailing arm rear, fully adjustable gas shocksRear Travel (in./cm.) 190 mm (7.4 in)BrakesBrake System Type Four wheel hydraulic disc + rear wheel parkingWheels & TiresFront Wheel Aluminum alloy (14 x 7 in)Rear Wheel Aluminum alloy (14 x 8 in)Front Tire AT 27 x 9-14Rear Tire AT 27 x 11-14DimensionsOverall Vehicle Size (LxWxH) 2310 x 1264 x 1420 mm (94.3 x 49.7 x 56 in)Wheelbase 1480 mm (58.2 in)Ground Clearance 285 mm (11 in)Turning Radius 3800 mm (149.6 in)CapacitiesFuel Capacity Tank: 28 L (7,3 gal)Towing Capacity 396 kg (873 lbs)

Box Capacity Front: 20 kg (44 lbs) |

Rear:

40 kg (88 lbs)

Weights

Weight Net: 490 kg (1080 lbs
