Engine Type:

Single-Cylinder

Cylinders:

1

Engine Stroke:

4-Stroke

Cooling:

Liquid

Valves:

4

Valves Per Cylinder:

4

Valve Configuration:

SOHC

Bore (mm):

102

Bore (in):

4.02

Stroke (mm):

84

Stroke (in):

3.31

Displacement (cc):

686

Displacement (ci):

41.9

Compression Ratio:

10.0:1

Starter:

Electric

Fuel Requirements:

Regular

Fuel Type:

Gas

Brakes

Front Brake Type:

Dual Hydraulic Disc

Rear Brake Type:

Hydraulic Disc

Carburetion

Fuel Injector:

Yes

Fuel Injector Size (mm):

44

Carburetion Type:

Fuel Injected

Dimensions

Length (in):

72.6

Length (mm):

1844

Width (in):

45.5

Width (mm):

1155.7

Height (in):

43.9

Height (mm):

1115.1

Wheelbase (in):

50.4

Wheelbase (mm):

1280.2

Ground Clearance (in):

9.5

Ground Clearance (mm):

241.3

Length (ft):

6.05

Length (ft/ft):

6

Length (ft/in):

0.6

Other Specifications

Other

Fuel Capacity (gal):

2.9

Fuel Capacity (l):

11

Frame:

Aluminum / Steel

Body Material:

Plastic

Driveline Type:

4X2

Number Of Driveline Modes:

1

Rear Solid Axle:

Yes

Floor Board Location:

Driver

Foot Peg Location:

Driver

Front Suspension Type:

Independent Double Wishbone

Front Travel (in):

9.1

Front Travel (mm):

231.1

Front Adjustable Fork Pre-Load:

Yes

Front Adjustable Rebound Damping:

Yes

Fuel Level Warning Type:

Light

SysModelID:

124806

Year:

2023

Manufacturer:

Yamaha

Model Name:

Raptor

Trim Name:

700R SE

Family Name:

Raptor

Product Type:

ATV

Manufacturer Type:

Sport ATV

Generic Type (Primary):

Sport

Manufacturer Country:

Japan

Photo Name:


Major Revision Year:

2015

Revision Status:

Carryover

Competitor Code:

ATV23SAF000

Manufacturer Recommend Minimum Age:

16

SysTrimId:

398232

SysMakeId:

1

IsCurrent:

Yes

Historical ID:

377079

Data Provider:

CRS

Parent Company:

Yamaha

Display Name:

Raptor 700R SE

Engine Displacement to Weight (cc):

1.63

Currency:

US Dollars

Warranty (Months):

6

Destination Charge:

460

Warranty (Condition):

Limited

Rear Suspension Type:

Swing Arm

Rear Travel (in):

10.1

Rear Travel (mm):

256.5

Rear Adjustable Shock / Spring Pre-Load:

Yes

Rear Adjustable Rebound Damping:

Yes

Number Rear Shock Absorbers:

1

Rear Suspension Material:

Aluminum

Seat Type:

One-Piece

Seat Material:

Vinyl

Seat Location:

Driver

Seat Height (in):

32.7

Seat Height (mm):

830.6

Number Of Seats:

1

Bash Plate (Front):

Yes

Steering Type:

Manual

Steering Control:

Handlebar

Temperature Warning Type:

Light

Tire Brand:

Maxxis®

Front Tire Width:

7

Front Wheel Diameter:

10

Rear Tire Width:

10

Rear Wheel Diameter:

9

Front Tire (Full Spec):

Maxxis® AT 22 X 7-10

Rear Tire (Full Spec):

Maxxis® AT 20 X 10-9

Wheels Composition:

Aluminum

Tube / Tubeless:

Tubeless

Front Tire Diameter (in):

22

Rear Tire Diameter (in):

20

Type:

LED
